Slope immediately downstream of the metering station can eliminate the possibility of submerged flow conditions. Long, narrow, flat or undersized channels can result in a backwater effect at the flume and should be avoided. Downstream channel : The downstream channel should not permit submerged flow conditions to occur. Made) must be level both longitudinally & transversely.ģ. Crest of the flume : The crest of the flume (the floor of the converging section where depth measurements are A 1 : 4 sloping ramp upstream should be provided for flumes that must beĢ. A slope of almost flat, to 3 % maximum, for very small flumes, and 2 % maximum for The upstream channel slope should not allowĮxcessive velocity at the flume. Turns, tees, elevation drops or other obstructions should be avoided. Upstream conditions : Upstream conditions should promote laminar flow conditions at the flume inlet. What are the three areas you should be concerned with for successful installation of a Parshall flume ?ġ. Flumes are restrictions in the channel and consideration should be given to the effect of the resulting backwater on upstream drains and channel walls or banks. In general, the smallest flume of adequate capacity is selected. Sizing of flumes is based on anticipated normal and maximum flows. What Size Parshall Flume Should I Purchase ?. Must be taken when mating Parshall flumes to circular channels. Parshall flumes can be use with non-full pipes if a suitable transition is provided, however extreme care Parshall Flumes are the standard for most waste water treatment plant influent and effluents. Parshall flumes are best used in channels Parshall flumes principle advantages include low head loss, self cleaning capability, and their ability to withstand relatively high degrees of submergence without affecting the rate of flow. The Parshall flume was developed by the US Soil Conservation Service in the 1920’s to measure irrigation water flow. In addition, all the other pics have thumbnails. To access the pics and table you want, just click on the explanatory item coloured You will find the content of the pics and Notice : This chapter includes some pics related to explanatory tables in accordance withįor a faster connecting, in the other words, for your convenience, pics and tables were marked by
